WIN11 Snap 是什么？自定义 WINDOW 如何使用 Snap 功能？快速学习WIN11 Snap功能及操作步骤

更新时间：2025-06-17 11:22:40作者：xhjaty

WIN11 Snap 是什么？自定义 WINDOW 如何使用 Snap 功能？

控件名：Snap

作者：WPFDevelopersOrg - 驚鏵

原文链接[1]：https://github.com/WPFDevelopersOrg/WPFDevelopers

码云链接[2]：https://gitee.com/WPFDevelopersOrg/WPFDevelopers

框架支持.NET4 至 .NET8；Visual Studio 2022;

Issue：Window 控件在 Win11 下不支持 Snap 功能[3]

Snap 是什么？

Snap Layouts 是 Windows 11 的一项新功能，但是系统版本号必须 ≥ 21H2 。

Snap Layouts

Snap Layouts 提供 6 种不同的布局；双窗口排列 2 种三窗口排列 3 种四窗口排列 1 种 WIN11 Snap 是什么？自定义 WINDOW 如何使用 Snap 功能？快速学习WIN11 Snap功能及操作步骤

提供了多种预设的窗口布局，可以将窗口快速调整到屏幕的左侧、右侧、上方、下方，甚至是四分之一屏幕区域；可以通过将窗口拖动到屏幕边缘来启动 Snap，或使用快捷键（Win + 左/右箭头、Win + 上/下箭头）来实现；在应用程序或窗口中按下「Win + Z」快捷键，或是将鼠标光标悬停在窗口最大化按钮上以显示 Snap Layout 菜单。分屏允许通过将屏幕的一半或四分之一，让多任务处理变得更加流畅，对于大屏幕或多显示器的用户尤其有用；如何在 WPF 中自定义 Window 支持 SnapLayout 功能1. 修改 Window.cs重写 OnSourceInitialized,实现 Win32 消息钩子 HwndSourceHook;WM_NCHITTEST：用于检测鼠标在 Window 的哪个区域;WM_NCLBUTTONDOWN：鼠标左键按下，是否在标题栏按钮;处理 Snap Layout 消息 HandleSnapLayoutMessage;获取当前最大化还是还原按钮;通过 lParam 获取鼠标屏幕坐标，是否在最大化或者还原按钮上;然后返回 HTMAXBUTTON 通知系统鼠标现在在最大化按钮上;

using Microsoft.Windows.Shell;
using System;
using System.Windows;
using System.Windows.Automation.Peers;
using System.Windows.Automation.Provider;
using System.Windows.Controls;
using System.Windows.Input;
using System.Windows.Interop;
using System.Windows.Media;
using WPFDevelopers.Controls;
using WPFDevelopers.Core.Helpers;
using WPFDevelopers.Helpers;

namespaceWPFDevelopers.Net40
{
 [TemplatePart(Name = TitleBarIcon, Type = typeof(Button))]
 [TemplatePart(Name = HighTitleMaximizeButton, Type = typeof(Button))]
 [TemplatePart(Name = HighTitleRestoreButton, Type = typeof(Button))]
 [TemplatePart(Name = TitleBarMaximizeButton, Type = typeof(Button))]
 [TemplatePart(Name = TitleBarRestoreButton, Type = typeof(Button))]
 publicclassWindow : System.Windows.Window
 {
 privateconststring TitleBarIcon = "PART_TitleBarIcon";
 privateconststring HighTitleMaximizeButton = "PART_MaximizeButton";
 privateconststring HighTitleRestoreButton = "PART_RestoreButton";
 privateconststring TitleBarMaximizeButton = "PART_TitleBarMaximizeButton";
 privateconststring TitleBarRestoreButton = "PART_TitleBarRestoreButton";
 private WindowStyle _windowStyle;
 private Button _titleBarIcon;
 private Button _highTitleMaximizeButton;
 private Button _highTitleRestoreButton;
 private Button _titleBarMaximizeButton;
 private Button _titleBarRestoreButton;
 private IntPtr hWnd;

 publicstaticreadonly DependencyProperty TitleHeightProperty =
 DependencyProperty.Register("TitleHeight", typeof(double), typeof(Window), new PropertyMetadata(50d));

 publicstaticreadonly DependencyProperty NoChromeProperty =
 DependencyProperty.Register("NoChrome", typeof(bool), typeof(Window), new PropertyMetadata(false));

 publicstaticreadonly DependencyProperty TitleBarProperty =
 DependencyProperty.Register("TitleBar", typeof(object), typeof(Window), new PropertyMetadata());

 publicstaticreadonly DependencyProperty TitleBackgroundProperty =
 DependencyProperty.Register("TitleBackground", typeof(Brush), typeof(Window), new PropertyMetadata());

 publicstaticreadonly DependencyProperty TitleBarModeProperty =
 DependencyProperty.Register("TitleBarMode", typeof(TitleBarMode), typeof(Window), new PropertyMetadata(TitleBarMode.Normal));

 static Window()
 {
 DefaultStyleKeyProperty.OverrideMetadata(typeof(Window), new FrameworkPropertyMetadata(typeof(Window)));
 }

 public Window()
 {
 WPFDevelopers.Resources.ThemeChanged += Resources_ThemeChanged;
 CommandBindings.Add(new CommandBinding(SystemCommands.CloseWindowCommand, CloseWindow));
 CommandBindings.Add(new CommandBinding(SystemCommands.MaximizeWindowCommand, MaximizeWindow,
 CanResizeWindow));
 CommandBindings.Add(new CommandBinding(SystemCommands.MinimizeWindowCommand, MinimizeWindow,
 CanMinimizeWindow));
 CommandBindings.Add(new CommandBinding(SystemCommands.RestoreWindowCommand, RestoreWindow,
 CanResizeWindow));
 }

 private void Resources_ThemeChanged(ThemeType currentTheme)
 {
 var isDark = currentTheme == ThemeType.Dark ? true : false;
 var source = (HwndSource)PresentationSource.FromVisual(this);
 Win32.EnableDarkModeForWindow(source, isDark);
 }

 public override void OnApplyTemplate()
 {
 base.OnApplyTemplate();
 _windowStyle = WindowStyle;
 _titleBarIcon = GetTemplateChild(TitleBarIcon) as Button;
 if (_titleBarIcon != )
 {
 _titleBarIcon.MouseDoubleClick -= Icon_MouseDoubleClick;
 _titleBarIcon.MouseDoubleClick += Icon_MouseDoubleClick;
 }
 _highTitleMaximizeButton = GetTemplateChild(HighTitleMaximizeButton) as Button;
 _highTitleRestoreButton = GetTemplateChild(HighTitleRestoreButton) as Button;
 _titleBarMaximizeButton = GetTemplateChild(TitleBarMaximizeButton) as Button;
 _titleBarRestoreButton = GetTemplateChild(TitleBarRestoreButton) as Button;
 }

 private void Icon_MouseDoubleClick(object sender, MouseButtonEventArgs e)
 {
 if (e.ChangedButton == MouseButton.Left)
 Close();
 }

 publicdouble TitleHeight
 {
 get => (double)GetValue(TitleHeightProperty);
 set => SetValue(TitleHeightProperty, value);
 }

 publicbool NoChrome
 {
 get => (bool)GetValue(NoChromeProperty);
 set => SetValue(NoChromeProperty, value);
 }

 publicobject TitleBar
 {
 get => (object)GetValue(TitleBarProperty);
 set => SetValue(TitleBarProperty, value);
 }

 public Brush TitleBackground
 {
 get => (Brush)GetValue(TitleBackgroundProperty);
 set => SetValue(TitleBackgroundProperty, value);
 }

 public TitleBarMode TitleBarMode
 {
 get => (TitleBarMode)GetValue(TitleBarModeProperty);
 set => SetValue(TitleBarModeProperty, value);
 }

 protected override void OnSourceInitialized(EventArgs e)
 {
 base.OnSourceInitialized(e);
 hWnd = new WindowInteropHelper(this).Handle;
 HwndSource.FromHwnd(hWnd).AddHook(WindowProc);
 if (TitleBarMode == TitleBarMode.Normal)
 TitleHeight = SystemParameters2.Current.WindowNonClientFrameThickness.Top;
 }

 protected override void OnContentRendered(EventArgs e)
 {
 base.OnContentRendered(e);
 if (SizeToContent == SizeToContent.WidthAndHeight)
 InvalidateMeasure();
 }

 #region Window Commands

 private void CanResizeWindow(object sender, CanExecuteRoutedEventArgs e)
 {
 e.CanExecute = ResizeMode == ResizeMode.CanResize || ResizeMode == ResizeMode.CanResizeWithGrip;
 }

 private void CanMinimizeWindow(object sender, CanExecuteRoutedEventArgs e)
 {
 e.CanExecute = ResizeMode != ResizeMode.NoResize;
 }

 private void CloseWindow(object sender, ExecutedRoutedEventArgs e)
 {
 SystemCommands.CloseWindow(this);
 }

 private void MaximizeWindow(object sender, ExecutedRoutedEventArgs e)
 {
 if (WindowState == WindowState.Normal)
 {
 WindowStyle = WindowStyle.SingleBorderWindow;
 WindowState = WindowState.Maximized;
 WindowStyle = WindowStyle.;
 }
 }

 private void MinimizeWindow(object sender, ExecutedRoutedEventArgs e)
 {
 Win32.SendMessage(hWnd, WindowsMessageCodes.WM_SYSCOMMAND, new IntPtr(WindowsMessageCodes.SC_MINIMIZE), IntPtr.Zero);
 }

 private void RestoreWindow(object sender, ExecutedRoutedEventArgs e)
 {
 SystemCommands.RestoreWindow(this);
 }


 private IntPtr WindowProc(IntPtr hwnd, int msg, IntPtr wParam, IntPtr lParam, ref bool handled)
 {
 switch (msg)
 {
 case WindowsMessageCodes.WM_SYSCOMMAND:
 if (wParam.ToInt32() == WindowsMessageCodes.SC_MINIMIZE)
 {
 _windowStyle = WindowStyle;
 if (WindowStyle != WindowStyle.SingleBorderWindow)
 WindowStyle = WindowStyle.SingleBorderWindow;
 WindowState = WindowState.Minimized;
 handled = true;
 }
 elseif (wParam.ToInt32() == WindowsMessageCodes.SC_RESTORE)
 {
 WindowState = WindowState.Normal;
 WindowStyle = WindowStyle.;
 if (WindowStyle. != _windowStyle)
 WindowStyle = _windowStyle;
 handled = true;
 }
 break;
 case WindowsMessageCodes.WM_NCHITTEST:
 case WindowsMessageCodes.WM_NCLBUTTONDOWN:
 try
 {
 if (!OSVersionHelper.IsSnapLayoutSupported()
 ||
 ResizeMode == ResizeMode.NoResize
 ||
 ResizeMode == ResizeMode.CanMinimize)
 break;
 else
 {
 IntPtr result = IntPtr.Zero;
 if (HandleSnapLayoutMessage(msg, lParam, ref result))
 {
 handled = true;
 return result;
 }
 }
 }
 catch (OverflowException)
 {
 handled = true;
 }
 break;
 }
 return IntPtr.Zero;
 }

 private bool HandleSnapLayoutMessage(int msg, IntPtr lParam, ref IntPtr result)
 {
 Button button = TitleBarMode == TitleBarMode.Normal
 ? (WindowState != WindowState.Maximized ? _titleBarMaximizeButton : _titleBarRestoreButton)
 : (WindowState != WindowState.Maximized ? _highTitleMaximizeButton : _highTitleRestoreButton);

 if (button ==  || button.ActualWidth <= 0 || button.ActualHeight <= 0)
 returnfalse;
 var contentPresenter = button.Template.FindName("PART_ContentPresenter", button) as ContentPresenter;
 var x = lParam.ToInt32() & 0xffff;
 var y = lParam.ToInt32() >> 16;
 var dpiX = OSVersionHelper.DeviceUnitsScalingFactorX;
 var rect = new Rect(button.PointToScreen(new Point()), new Size(button.ActualWidth * dpiX, button.ActualHeight * dpiX));
 var point = new Point(x, y);

 if (msg == WindowsMessageCodes.WM_NCHITTEST && contentPresenter != )
 {
 if (!rect.Contains(point))
 {
 if(contentPresenter.Opacity != 0.7)
 contentPresenter.Opacity = 0.7;
 returnfalse;
 }
 contentPresenter.Opacity = 1;
 result = new IntPtr(OSVersionHelper.HTMAXBUTTON);
 }
 elseif (msg == WindowsMessageCodes.WM_NCLBUTTONDOWN)
 {
 IInvokeProvider invokeProv = new ButtonAutomationPeer(button).GetPattern(PatternInterface.Invoke) as IInvokeProvider;
 invokeProv?.Invoke();
 }

 returntrue;
 }


 private void ShowSystemMenu(object sender, ExecutedRoutedEventArgs e)
 {
 var element = e.OriginalSource as FrameworkElement;
 if (element == )
 return;

 var point = WindowState == WindowState.Maximized
 ? new Point(0. element.ActualHeight)
 : new Point(Left + BorderThickness.Left, element.ActualHeight + Top + BorderThickness.Top);
 point = element.TransformToAncestor(this).Transform(point);
 SystemCommands.ShowSystemMenu(this, point);
 }

 #endregion
 }
}

2. 修改 Window.xaml

<Style BasedOn="{x:}" TargetType="{x:Type wd:Window}">
 <Setter Property="Foreground" Value="{DynamicResource WD.RegularTextBrush}" />
 <Setter Property="Background" Value="{DynamicResource WD.BackgroundBrush}" />
 <Setter Property="BorderBrush" Value="{DynamicResource WD.WindowBorderBrush}" />
 <Setter Property="TitleBackground" Value="{DynamicResource WD.WindowBorderBrush}" />
 <Setter Property="IsTabStop" Value="False" />
 <Setter Property="BorderThickness" Value="1" />
 <Setter Property="SnapsToDevicePixels" Value="True" />
 <Setter Property="UseLayoutRounding" Value="True" />
 <Setter Property="TextOptions.TextFormattingMode" Value="Ideal" />
 <Setter Property="WindowStyle" Value="" />
 <Setter Property="FontFamily" Value="{DynamicResource WD.FontFamily}" />
 <Setter Property="shell:WindowChrome.WindowChrome">
 <Setter.Value>
 <shell:WindowChrome CaptionHeight="{Binding TitleHeight, RelativeSource={RelativeSource AncestorType=wd:Window}}" GlassFrameThickness="0.0.0..1" />
 </Setter.Value>
 </Setter>
 <Setter Property="Template">
 <Setter.Value>
 <ControlTemplate TargetType="{x:Type wd:Window}">
 <Border
 Name="PART_Border"
 Background="{TemplateBinding Background}"
 BorderBrush="{TemplateBinding BorderBrush}"
 BorderThickness="{TemplateBinding BorderThickness}"
 SnapsToDevicePixels="True">
 <Grid x:Name="LayoutRoot">
 <Grid.RowDefinitions>
 <RowDefinition Height="Auto" />
 <RowDefinition Height="*" />
 </Grid.RowDefinitions>
 <control:SmallPanel
 x:Name="PART_Normal"
 Grid.Row="0"
 Background="{TemplateBinding TitleBackground}">
 <Grid Height="{TemplateBinding TitleHeight}">
 <Grid.ColumnDefinitions>
 <ColumnDefinition Width="*" />
 <ColumnDefinition Width="Auto" />
 </Grid.ColumnDefinitions>
 <StackPanel Orientation="Horizontal">
 <Button
 x:Name="PART_TitleBarIcon"
 Margin="5,0.0.0"
 VerticalAlignment="Center"
 shell:WindowChrome.IsHitTestVisibleInChrome="True"
 Background="Transparent"
 BorderThickness="0"
 Visibility="{Binding Icon, RelativeSource={RelativeSource Mode=TemplatedParent}, Converter={StaticResource ObjectToVisibilityConverter}}">
 <Image
 Width="{x:Static SystemParameters.SmallIconWidth}"
 Height="{x:Static SystemParameters.SmallIconHeight}"
 IsHitTestVisible="False"
 RenderOptions.BitmapScalingMode="HighQuality"
 Source="{TemplateBinding Icon}" />
 </Button>

 <ContentControl
 Margin="5,0.0.0"
 VerticalAlignment="Center"
 Content="{TemplateBinding Title}"
 FontSize="{DynamicResource {x:Static SystemFonts.CaptionFontSizeKey}}"
 Foreground="{DynamicResource WD.WindowTextBrush}"
 IsTabStop="False" />
 </StackPanel>
 <StackPanel
 Grid.Column="1"
 HorizontalAlignment="Right"
 VerticalAlignment="Top"
 shell:WindowChrome.IsHitTestVisibleInChrome="True"
 Orientation="Horizontal">
 <StackPanel x:Name="PART_TitleBarMinAndMax" Orientation="Horizontal">
 <Button
 x:Name="PART_TitleBarMinimizeButton"
 Padding="0"
 Command="{Binding Source={x:Static shell:SystemCommands.MinimizeWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Minimize], Source={x:Static resx:LanguageManager.Instance}}">
 <Grid HorizontalAlignment="Center" VerticalAlignment="Center">
 <Rectangle
 Width="10"
 Height="1"
 Margin="0.7,0.0"
 VerticalAlignment="Bottom"
 Fill="{DynamicResource WD.WindowTextBrush}" />
 </Grid>
 </Button>
 <Button
 x:Name="PART_TitleBarMaximizeButton"
 Padding="0"
 Command="{Binding Source={x:Static shell:SystemCommands.MaximizeWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Maximize], Source={x:Static resx:LanguageManager.Instance}}">
 <Grid HorizontalAlignment="Center" VerticalAlignment="Center">
 <Path
 Width="10"
 Height="10"
 HorizontalAlignment="Center"
 VerticalAlignment="Center"
 Data="{DynamicResource WD.WindowMaximizeGeometry}"
 Fill="{DynamicResource WD.WindowTextBrush}"
 Stretch="Uniform"
 UseLayoutRounding="False" />
 </Grid>
 </Button>
 <Button
 x:Name="PART_TitleBarRestoreButton"
 Padding="0"
 Command="{Binding Source={x:Static shell:SystemCommands.RestoreWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Restore], Source={x:Static resx:LanguageManager.Instance}}"
 Visibility="Collapsed">
 <Grid HorizontalAlignment="Center" VerticalAlignment="Center">
 <Path
 Width="10"
 Height="10"
 HorizontalAlignment="Center"
 VerticalAlignment="Center"
 Data="{DynamicResource WD.WindowRestoreGeometry}"
 Fill="{DynamicResource WD.WindowTextBrush}"
 Stretch="Uniform"
 UseLayoutRounding="False" />
 </Grid>
 </Button>
 </StackPanel>

 <Button
 Name="PART_TitleBarCloseButton"
 Command="{Binding Source={x:Static shell:SystemCommands.CloseWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Close], Source={x:Static resx:LanguageManager.Instance}}">
 <Path
 Width="10"
 Height="10"
 HorizontalAlignment="Center"
 VerticalAlignment="Center"
 Data="{DynamicResource WD.WindowCloseGeometry}"
 Fill="{DynamicResource WD.WindowTextBrush}"
 Stretch="Uniform" />
 </Button>
 </StackPanel>
 </Grid>
 </control:SmallPanel>
 <control:SmallPanel
 x:Name="PART_HighTitleBar"
 Grid.Row="0"
 Background="{TemplateBinding TitleBackground}"
 Visibility="Collapsed">
 <Grid
 x:Name="PART_GridChrome"
 Height="{TemplateBinding TitleHeight}"
 Margin="10.0.0.0">
 <Grid.ColumnDefinitions>
 <ColumnDefinition Width="Auto" />
 <ColumnDefinition Width="*" />
 <ColumnDefinition Width="Auto" MinWidth="30" />
 </Grid.ColumnDefinitions>
 <Image
 Width="23"
 Height="23"
 VerticalAlignment="Center"
 RenderOptions.BitmapScalingMode="HighQuality"
 Source="{TemplateBinding Icon}"
 Visibility="{TemplateBinding Icon,
 Converter={StaticResource ObjectToVisibilityConverter}}" />
 <TextBlock
 x:Name="PART_Title"
 Grid.Column="1"
 Margin="6,0"
 VerticalAlignment="Center"
 FontSize="{DynamicResource WD.TitleFontSize}"
 Foreground="{DynamicResource WD.WindowTextBrush}"
 Text="{TemplateBinding Title}" />
 <StackPanel
 Grid.Column="2"
 Margin="0.6"
 shell:WindowChrome.IsHitTestVisibleInChrome="True"
 Orientation="Horizontal">
 <StackPanel x:Name="PART_MinAndMax" Orientation="Horizontal">
 <Button
 Name="PART_MinimizeButton"
 Padding="0"
 Command="{Binding Source={x:Static shell:SystemCommands.MinimizeWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Minimize], Source={x:Static resx:LanguageManager.Instance}}">
 <Grid HorizontalAlignment="Center" VerticalAlignment="Center">
 <Rectangle
 x:Name="MinimizeGlyph"
 Width="10"
 Height="1"
 Margin="0.7,0.0"
 VerticalAlignment="Bottom"
 Fill="{DynamicResource WD.WindowTextBrush}" />
 </Grid>
 </Button>
 <Button
 x:Name="PART_MaximizeButton"
 Padding="0"
 Command="{Binding Source={x:Static shell:SystemCommands.MaximizeWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Maximize], Source={x:Static resx:LanguageManager.Instance}}">
 <Grid HorizontalAlignment="Center" VerticalAlignment="Center">
 <Path
 Width="10"
 Height="10"
 HorizontalAlignment="Center"
 VerticalAlignment="Center"
 Data="{DynamicResource WD.WindowMaximizeGeometry}"
 Fill="{DynamicResource WD.WindowTextBrush}"
 Stretch="Uniform"
 UseLayoutRounding="False" />
 </Grid>
 </Button>
 <Button
 x:Name="PART_RestoreButton"
 Padding="0"
 Command="{Binding Source={x:Static shell:SystemCommands.RestoreWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Restore], Source={x:Static resx:LanguageManager.Instance}}"
 Visibility="Collapsed">
 <Grid HorizontalAlignment="Center" VerticalAlignment="Center">
 <Path
 Width="10"
 Height="10"
 HorizontalAlignment="Center"
 VerticalAlignment="Center"
 Data="{DynamicResource WD.WindowRestoreGeometry}"
 Fill="{DynamicResource WD.WindowTextBrush}"
 Stretch="Uniform"
 UseLayoutRounding="False" />
 </Grid>
 </Button>
 </StackPanel>

 <Button
 Name="PART_CloseButton"
 Command="{Binding Source={x:Static shell:SystemCommands.CloseWindowCommand}}"
 IsTabStop="False"

 ToolTip="{Binding [Close], Source={x:Static resx:LanguageManager.Instance}}">
 <Path
 Width="10"
 Height="10"
 HorizontalAlignment="Center"
 VerticalAlignment="Center"
 Data="{DynamicResource WD.WindowCloseGeometry}"
 Fill="{DynamicResource WD.WindowTextBrush}"
 Stretch="Uniform" />
 </Button>
 </StackPanel>
 </Grid>
 <ContentPresenter
 x:Name="PART_TitleToolBar"
 shell:WindowChrome.IsHitTestVisibleInChrome="True"
 Content="{Binding TitleBar, RelativeSource={RelativeSource TemplatedParent}, Mode=OneWay}"
 Focusable="False"
 Visibility="Collapsed" />
 </control:SmallPanel>
 <AdornerDecorator Grid.Row="1" KeyboardNavigation.IsTabStop="False">
 <ContentPresenter x:Name="MainContentPresenter" ClipToBounds="True" />
 </AdornerDecorator>
 <ResizeGrip
 x:Name="ResizeGrip"
 Grid.Row="1"
 HorizontalAlignment="Right"
 VerticalAlignment="Bottom"
 IsTabStop="False"
 Visibility="Collapsed" />
 </Grid>
 </Border>
 <ControlTemplate.Triggers>
 <Trigger Property="TitleBarMode" Value="HighTitleBar">
 <Setter TargetName="PART_HighTitleBar" Property="Visibility" Value="Visible" />
 <Setter TargetName="PART_Normal" Property="Visibility" Value="Collapsed" />
 </Trigger>
 <Trigger Property="WindowState" Value="Maximized">
 <Setter TargetName="PART_RestoreButton" Property="Visibility" Value="Visible" />
 <Setter TargetName="PART_MaximizeButton" Property="Visibility" Value="Collapsed" />
 <Setter TargetName="PART_TitleBarRestoreButton" Property="Visibility" Value="Visible" />
 <Setter TargetName="PART_TitleBarMaximizeButton" Property="Visibility" Value="Collapsed" />
 <Setter TargetName="PART_Border" Property="Margin" Value="7" />
 </Trigger>
 <Trigger Property="WindowStyle" Value="ToolWindow">
 <Setter TargetName="PART_MinAndMax" Property="Visibility" Value="Collapsed" />
 <Setter TargetName="PART_TitleBarMinAndMax" Property="Visibility" Value="Collapsed" />
 </Trigger>
 <Trigger Property="NoChrome" Value="True">
 <Setter TargetName="PART_GridChrome" Property="Visibility" Value="Collapsed" />
 <Setter TargetName="PART_TitleToolBar" Property="Visibility" Value="Visible" />
 </Trigger>
 <MultiTrigger>
 <MultiTrigger.Conditions>
 <Condition Property="ResizeMode" Value="CanResizeWithGrip" />
 <Condition Property="WindowState" Value="Normal" />
 </MultiTrigger.Conditions>
 <Setter TargetName="ResizeGrip" Property="Visibility" Value="Visible" />
 </MultiTrigger>
 </ControlTemplate.Triggers>
 </ControlTemplate>
 </Setter.Value>
 </Setter>
</Style>

3. 新增 OSVersionHelper.cs构造函数获取 DPI 信息;IsSnapLayoutSupported() 方法用于判断系统是否支持 Snap 布局;获取 Windows 版本号;

using Microsoft.Win32;
using System;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Controls.Primitives;
using System.Windows.Interop;
using System.Windows.Media;
using WPFDevelopers.Helpers;

namespaceWPFDevelopers.Core.Helpers
{
 publicclassOSVersionHelper
 {
 privateconstdouble LogicalDpi = 96.0;
 publicstatic MatrixTransform TransformFromDevice { get; }
 publicstatic MatrixTransform TransformToDevice { get; }

 publicstaticdouble DeviceDpiX { get; }

 publicstaticdouble DeviceDpiY { get; }
 publicstaticdouble DeviceUnitsScalingFactorX => TransformToDevice.Matrix.M11;

 publicstaticdouble DeviceUnitsScalingFactorY => TransformToDevice.Matrix.M22;

 privatestaticbool? _isSnapLayoutSupported;

 public static bool IsSnapLayoutSupported()
 {
 if (_isSnapLayoutSupported.HasValue)
 {
 return _isSnapLayoutSupported.Value;
 }

 _isSnapLayoutSupported = CheckSnapLayoutSupport();
 return _isSnapLayoutSupported.Value;
 }


 static OSVersionHelper()
 {
 var dC = Win32.GetDC(IntPtr.Zero);
 if (dC != IntPtr.Zero)
 {
 constint logicPixelsX = 88;
 constint logicPixelsY = 90;
 DeviceDpiX = Win32.GetDeviceCaps(dC, logicPixelsX);
 DeviceDpiY = Win32.GetDeviceCaps(dC, logicPixelsY);
 Win32.ReleaseDC(IntPtr.Zero, dC);
 }
 else
 {
 DeviceDpiX = LogicalDpi;
 DeviceDpiY = LogicalDpi;
 }

 var identity = Matrix.Identity;
 var identity2 = Matrix.Identity;
 identity.Scale(DeviceDpiX / LogicalDpi, DeviceDpiY / LogicalDpi);
 identity2.Scale(LogicalDpi / DeviceDpiX, LogicalDpi / DeviceDpiY);
 TransformFromDevice = new MatrixTransform(identity2);
 TransformFromDevice.Freeze();
 TransformToDevice = new MatrixTransform(identity);
 TransformToDevice.Freeze();
 }

 private static bool CheckSnapLayoutSupport()
 {
 var version = GetWindowsBuildNumber();
 return version >= 22000;
 }

 private static int GetWindowsBuildNumber()
 {
 try
 {
 using (RegistryKey key = Registry.LocalMachine.OpenSubKey(@"SOFTWARE\Microsoft\Windows NT\CurrentVersion"))
 {
 if (key != )
 {
 var buildNumber = key.GetValue("CurrentBuildNumber");
 if (buildNumber !=  && int.TryParse(buildNumber.ToString(), outint result))
 {
 return result;
 }
 }
 }
 }
 catch
 {

 }
 return0;
 }

 #region SnapLayout
 privateconstdouble DPI_SCALE = 1.5;
 publicconstint HTMAXBUTTON = 9;

 private static HwndSource GetWindowHwndSource(DependencyObject dependencyObject)
 {
 if (dependencyObject is Window window)
 {
 return PresentationSource.FromVisual(window) as HwndSource;
 }
 elseif (dependencyObject is ToolTip tooltip)
 {
 return PresentationSource.FromVisual(tooltip) as HwndSource;
 }
 elseif (dependencyObject is Popup popup)
 {
 if (popup.Child is)
 return;

 return PresentationSource.FromVisual(popup.Child) as HwndSource;
 }
 elseif (dependencyObject is Visual visual)
 {
 return PresentationSource.FromVisual(visual) as HwndSource;
 }
 return;
 }
 #endregion
 }
}
